System Architecture |
| Form Factor | Proprietary |
Construction |
| Type | Fanless |
Graphic |
| Interfaces | DisplayPort, DVI, LVDS, HDMI, VGA, eDP |
Ethernet |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces |
| COM Total | 2 |
| RS-232 | 2 |
| RS-232/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Drive interfaces |
| SD Slots | 1 |
Extension Slots |
| Total | 4 |
| PCI Express x16 | 1 |
| PCI Express x4 | 1 |
| PCI Express x1 | 2 |
| Mini-PCIe/Mini Card | 2 |
Connectors |
| Internal Ports | 2xCOM, 10-pin DIO, 2x20-pin LVDS, 5-pin SMBus, 2x220-pin COM Express, I2C, 40-pin eDP |
| Connectors | 2xDB9, DVI, DB15 VGA, HDMI, RJ45 Ethernet, 6xUSB, Mic In, Line In, Line Out, Display Port |
Dimensions and weight |
| Width | 244 mm |
| Length | 291 mm |
Operating Conditions |
| Operating Temperature | -40...85 °C |
Standards and Certifications |
| Certifications | CE |
