System Architecture | |
| Form Factor | COM Express Basic |
Construction | |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Skylake |
| Processor Installed | Intel Core i7-6820EQ |
| Max CPU frequency | 3.5 GHz |
Chipset | |
| Chipset | Intel QM170 PCH |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | LVDS, 3xDDI |
Ethernet | |
| Controller Type | Intel i219-LM |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| USB Total | 12 |
| USB 2.0 | 8 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
Extension Slots | |
| PCI Express x16 | 1 |
| PCI Express x1 | 8 |
Additional Functions | |
| Watchdog timer type | Hardware |
Dimensions and weight | |
| Width | 125 mm |
| Length | 95 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
Standards and Certifications | |
| Certifications | CE |
