System Architecture | |
| Form Factor | COM Express Basic |
CPU | |
| СPU Generation/Family | Coffee Lake |
| Processor Installed | Intel Core i7-9850HE |
| Max CPU frequency | 4.4 GHz |
Chipset | |
| Chipset | Intel QM370 |
Memory | |
| Socket Type | 2xSODIMM |
| Maximum Memory | 96 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel UHD Graphics |
| Interfaces | LVDS, VGA, DDI |
Ethernet | |
| Controller Type | Intel i219-LM |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| USB Total | 12 |
| USB 2.0 | 8 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Drive interfaces | |
| SATA 3 | 4 |
| RAID Levels | 1, 5, 10 |
Extension Slots | |
| Total | 9 |
| PCI Express x16 | 1 |
| PCI Express x1 | 8 |
Additional Functions | |
| Watchdog timer type | Software |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 125 mm |
| Length | 95 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
Standards and Certifications | |
| Certifications | CE |
