System Architecture | |
| Form Factor | COM Express Compact |
CPU | |
| СPU Generation/Family | Apollo Lake |
| Processor Installed | Intel Atom E3930 |
| Max CPU frequency | 1.8 GHz |
Chipset | |
| Chipset | Intel Apollo Lake SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel Gen9 Graphic engine |
| Interfaces | LVDS, 2xDDI |
Ethernet | |
| Controller Type | Intel i211, Intel i210 |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| USB Total | 8 |
| USB 2.0 | 5 |
| USB v3.x | 3 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| SATA 3 | 2 |
Extension Slots | |
| PCI Express x1 | 3 |
Software | |
| Operating System Compatibility | Linux OS, Vxworks, Windows 10 |
Dimensions and weight | |
| Width | 95 mm |
| Length | 95 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
| Humidity | 5-95% |
