Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall |
| Protection Level of Chassis | IP20 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, Modbus RTU slave, MQTT client, DCON slave |
Ethernet | |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
System Power Input | |
| Power over Ethernet (PoE) | PoE |
| Input Voltage DC | 10...30 V |
Interfaces | |
| COM Total | 1 |
| RS-485 | 1 |
Sensors | |
| Measuring Range | -10...+50 °С |
| Resolution | 0.1 °C |
| Accuracy (+/-) | 0.6 °C |
| Measuring Range | 0…100% |
| Resolution | 0 % |
| Accuracy (+/-) | 0 % |
| Types of gases and particles measured | (O2) |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Dimensions and weight | |
| Width | 150 mm |
| Height | 53 mm |
