Construction | |
| Mounting Configuration | Desktop, Wall VESA 100 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 21.5 " |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 3000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
Chipset | |
| Chipset | Intel Skylake SoC |
Memory | |
| Default on Board Memory | 4 GB |
| Maximum Memory | 32 GB |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 3 |
| RS-232 | 2 |
| RS-232/422/485 | 1 |
| USB Total | 6 |
| USB 2.0 | 2 |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | DB9, 3xDB9, HDMI, 6xUSB, Mic In, Line Out, Display Port |
Power Supply | |
| Output Power | 84 W |
Software | |
| Operating System Compatibility | Windows 7, Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 528 mm |
| Height | 345 mm |
| Depth | 62 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
