Construction | |
| Mounting Configuration | DIN-Rail mount |
| Type | Fanless |
CPU | |
| Processor Installed | Vortex86DX3 |
| Max CPU frequency | 1 GHz |
Memory | |
| Form-factor | DDR3 |
| Default on Board Memory | 1 GB |
Graphic | |
| Graphic Controller | Integrated in Chipset |
Ethernet | |
| 10/100/1000 Mbit/s | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| USB 2.0 | 3 |
Drive interfaces | |
| SD Slots | 1 |
Connectors | |
| Connectors | DB15 VGA, 2xRJ45, 2xUSB |
System Power Input | |
| Input Voltage DC | 8...15 V |
Software | |
| Operating System Compatibility | Windows XP, Windows XP Embedded, Windows 7, Linux OS |
Dimensions and weight | |
| Width | 152 mm |
| Height | 104 mm |
| Depth | 54 mm |
Operating Conditions | |
| Operating Temperature | 5...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC, VCCI |
| EMI | EN 61000-3-2, EN 61000-3-3, EN 55024 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-9, IEC 61000-4-11, EN 55024 |
