Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 3 U |
| Type | Fanless |
CPU |
| Processor Installed | Intel Core i7-7820EQ |
| Max CPU frequency | 3.7 GHz |
Memory |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic |
| Graphic Controller | Intel HD Graphics 620 |
| Interfaces | 2xHDMI, VGA |
Ethernet |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 3 |
| USB v3.x | 3 |
Drive interfaces |
| RAID Levels | 1, 5, 10 |
Storage Cage |
| Number Of Cage External | 4 |
| Cage Door | Yes |
| 2.5" Cage External | 4 |
Extension Slots |
| Total | 5 |
| PCI Express x16 | 1 |
| PCI Express x4 | 1 |
| PCI Express x1 | 2 |
| PCI | 1 |
LED / Controls |
| LED | 1xHDD LED, Power Fail, Programmable LED Light Bar Indicator |
Connectors |
| Internal Ports | USB 2.0 |
System Power Input |
| Input Voltage AC | 100...240 V |
| Input Voltage DC | 100...240 V |
Software |
| Operating System Compatibility | Linux OS, Windows 10, Windows Server 2016 |
Dimensions and weight |
| Width | 440 mm |
| Height | 132.8 mm |
| Depth | 281 mm |
Operating Conditions |
| Operating Temperature | -25...55 °C |
Standards and Certifications |
| Certifications | EN61000-6-2, EN61000-6-4 |
| EMI | FCC Part 15 Subpart B Class A, CISPR 32 |
| High Availability Automation Networks | IEC 62439-3 |
| Power Automation | IEC 61850-3, IEEE 1613, IEC 60255 |
