System Architecture | |
| System Bus | Universal PCI |
Analog Input | |
| Total channels of analog input | 4 |
| Differential channels | 4 |
| Number of Bits | 16 Bit |
| Sampling rate | 250 Hz |
| Voltage range | +/-1.25 V, +/-2.5 V, +/-5 V, +/-10 V, 0...2.5 V, 0...5 V, 0...10 V |
Analog Output | |
| Channels of analog input | 2 |
| Voltage range | 0...10 V, +/-10 V |
Digital Input-Output | |
| Channels of DIO | 24 |
Digital Input | |
| Number of channels | 2 |
| Counter capacity | 16 Bit |
| Max frequency | 40 kHz |
| Signal Type | Frequency |
Connectors | |
| Connectors | 68-pin SCSI VHDCI |
Software | |
| Operating System Compatibility | Windows XP, Windows 7, Linux OS |
| Development Software | Visual Studio .NET, MATLAB, LabVIEW, AD-Logger, DAQBench |
Operating Conditions | |
| Operating Temperature | 0...55 °C |
