Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Desktop, Wall |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Alder Lake |
| Processor Installed | Intel Core i5-1235U |
| Socket | CPU onboard |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Socket Type | 2xSODIMM 260-pin |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel Iris Xe Graphics, Intel UHD Graphics |
Ethernet | |
| Controller Type | Intel i219-LM, Realtek RTL8111H |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 7 |
| USB 2.0 | 2 |
Extension Slots | |
| Total | 3 |
| M.2 | 3 |
Connectors | |
| Connectors | 2xDB9, 2xHDMI, 2xRJ45, 6xUSB, Mic In, Line Out, DC Input, Display Port, SIM Card Slot, USB type C |
System Power Input | |
| Power Consumption | 65 W |
Software | |
| Operating System Compatibility | Ubuntu, Windows 11 |
Dimensions and weight | |
| Width | 200 mm |
| Height | 150 mm |
| Depth | 40 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
