Ethernet | |
| Total Ethernet | 4 |
| 10/100 Mbit/s | 4 |
Interfaces | |
| COM Total | 16 |
| RS-485 | 8 |
| RS-232/485 | 8 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP, Modbus RTU, 60870-5-101 master, 60870-5-101 slave, 60870-5-104 client, 60870-5-104 server, DNP3, IEC61850 MMS server |
| Managment Protocols | NTP |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
| Humidity | 5-95% |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
Dimensions and weight | |
| Width | 483 mm |
| Depth | 200 mm |
| Height | 45 mm |
Standards and Certifications | |
| Certifications | CE |
| EMS | IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-8, IEC 61000-4-9, IEC 61000-4-10, IEC 61000-4-11, IEC 61000-4-12 |
| Safety | EN 60950-1, IEC 60950-1 |
