Specification
System Architecture | |
| System Bus | ISA |
Digital Input-Output | |
| Channels of DIO | 48 |
Digital Input | |
| Total channels of digital input | 48 |
| Level of Logic "0" | 0~0.4 V |
| Level of Logic "1" | 2~5 V |
| Number of channels | 3 |
| Counter capacity | 16 Bit |
| Max frequency | 10 kHz |
Digital Output | |
| Total channels of digital output | 48 |
| Output voltage | 0~5 V |
| Max. load current | 0.8 mA |
Connectors | |
| Internal Ports | 2x50-pin box header |
Software | |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
