DL-1023

Ціна за запитом
PM1/2.5/10/Temperature/Humidity/Dew Point/CO/CO2 Data Logger Module, Ethernet/PoE, DCON, Modbus RTU/TCP, MQTT, IP43, RoHS

Specification

Construction

Construction ChassisPlastic Chassis
Mounting ConfigurationWall, DIN-Rail mount
Protection Level of ChassisIP43

Supported Protocols

Industrial ProtocolsModbus TCP server, Modbus RTU slave, MQTT client

System Power Input

Power over Ethernet (PoE)IEEE 802.3af
Input Voltage DC12...48 V

Interfaces

RS-4851

Sensors

Measuring Range-20...+50 °С
Resolution0.1 °C
Accuracy (+/-)0.6 °C
Measuring Range0…100%
Resolution0 %
Accuracy (+/-)0 %
Measuring RangeCalculated using temperature and relative humidity
Types of gases and particles measured(CO2), (PM2.5)

Digital Output

Total channels of digital output1
TypeSignal Relay

Operating Conditions

Operating Temperature-20...50 °C

Dimensions and weight

Width130 mm
Depth70 mm
Height210 mm
