Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP43 |
Supported Protocols | |
| Industrial Protocols | MQTT broker, Modbus TCP server, Modbus RTU slave |
Ethernet | |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
System Power Input | |
| Power over Ethernet (PoE) | IEEE 802.3af |
Interfaces | |
| COM Total | 1 |
| RS-485 | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11b/g/n |
Sensors | |
| Measuring Range | -10...+50 °С |
| Resolution | 0.1 °C |
| Accuracy (+/-) | 0.6 °C |
| Measuring Range | 0…100% |
| Resolution | 0 % |
| Accuracy (+/-) | 0 % |
| Measuring Range | Calculated using temperature and relative humidity |
| Types of gases and particles measured | (CO2), (CO), (TVOC) |
Digital Output | |
| Total channels of digital output | 4 |
| Type | Signal Relay |
Operating Conditions | |
| Operating Temperature | -20...50 °C |
| Humidity | 10-90% |
Dimensions and weight | |
| Width | 130 mm |
| Depth | 70 mm |
| Height | 210 mm |
Standards and Certifications | |
| Certifications | CE |
