Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP43 |
Supported Protocols |
| Industrial Protocols | Modbus TCP server, Modbus RTU slave, MQTT client |
Ethernet |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
System Power Input |
| Power over Ethernet (PoE) | IEEE 802.3af |
| Input Voltage DC | 12...48 V |
Interfaces |
| RS-485 | 1 |
Sensors |
| Measuring Range | -20...+50 °С |
| Resolution | 0.1 °C |
| Accuracy (+/-) | 0.6 °C |
| Measuring Range | 0…100% |
| Resolution | 0 % |
| Accuracy (+/-) | 0 % |
| Measuring Range | Calculated using temperature and relative humidity |
| Types of gases and particles measured | (O2) |
Digital Output |
| Total channels of digital output | 4 |
| Type | PhotoMos relay |
Operating Conditions |
| Operating Temperature | -20...50 °C |
Dimensions and weight |
| Width | 130 mm |
| Depth | 70 mm |
| Height | 210 mm |
