Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
Display | |
| Display Type | LCD TFT |
| Diagonal | 2.8 " |
| Maximum resolution | 320x240 Dots |
Supported Protocols | |
| Industrial Protocols | Modbus TCP server, Modbus RTU slave, MQTT client, DCON slave |
Ethernet | |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| RS-485 | 1 |
Sensors | |
| Measuring Range | -10...+50 °С |
| Resolution | 0.1 °C |
| Accuracy (+/-) | 0.6 °C |
| Measuring Range | 0…100% |
| Resolution | 0 % |
| Types of gases and particles measured | (CO) |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Dimensions and weight | |
| Width | 106 mm |
| Depth | 56 mm |
| Height | 114 mm |
