Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Type | Fanless |
CPU | |
| Processor Installed | ARM Cortex |
Memory | |
| Form-factor | DDR4 |
| Socket Type | Soldered |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Integrated in Chipset |
Ethernet | |
| Controller Type | Intel i210-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| USB Total | 3 |
| USB 2.0 | 1 |
| USB v3.x | 2 |
Drive interfaces | |
| MicroSD | 1 |
Extension Slots | |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | 1 |
Antenna characteristics | |
| Cellular interfaces | 3G (Optional) |
Connectors | |
| Connectors | HDMI, 2xRJ45 Ethernet, 2xUSB, DC Input, 1xMicro USB |
System Power Input | |
| Input Voltage DC | 12...12 V |
Software | |
| Operating System Compatibility | Ubuntu |
Dimensions and weight | |
| Width | 147 mm |
| Height | 52 mm |
| Depth | 118 mm |
Operating Conditions | |
| Operating Temperature | -30...50 °C |
| Vibration | 3 Grms @ 5 ~ 500 Hz. random. 1 hr/axis |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Safety | CCC, UL, BSMI |
