Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i5-9500TE |
| Max CPU frequency | 3.6 GHz |
Chipset | |
| Chipset | Intel C246 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 8 GB |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i211, Intel i219-LM |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 3 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 7 |
| USB 2.0 | 4 |
| USB v3.x | 3 |
Digital Input | |
| Isolation DIO | Yes |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
| CFast Slots | 1 |
Storage Cage | |
| Number Of Cage External | 4 |
| 2.5" Cage External | 4 |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 2 |
| PCI Express x8 | 2 |
| PCI Express x4 | 1 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | Multi-SIM |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 4xDB9, DVI-I, 3xRJ45 Ethernet, 6xUSB, Mic In, Line Out, 2xDisplayPort, 1xDB15 DIO, DC input (terminal block), CFast slot |
System Power Input | |
| Input Voltage DC | 24...24 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 160 W |
Software | |
| Operating System Compatibility | Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 210 mm |
| Height | 210 mm |
| Depth | 350 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Vibration | 5 Grms. 5-500 Hz. 3 axes (w/ CFast or SSD) |
| Shock | 50 G. half sine 11 ms duration (w/ CFast or SSD) |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Safety | UL/cUL, CB |
