Ethernet |
| 10/100/1000 Mbit/s | 8 |
| ethernet_poe_1000mbit | 8 |
| ethernet_poe_standard | 802_3at |
Switch Properties |
| MAC Table Size | 4000 |
| Packet Buffer Size | 1.5 kBit |
| Jumbo Frame Size | 9.22 kB |
Supported Protocols |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3az for Energy-Efficient Ethernet, IEEE 802.3u for 100BaseT(X) |
Construction |
| Construction Chassis | Metal Chassis, Aluminium Chassis |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Depth | 45 mm |
| Height | 145 mm |
Standards and Certifications |
| EMI | FCC Part 15 Subpart B Class A, CISPR 22 Class |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-2, EN 61000-6-4 |
