Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Whiskey Lake |
| Processor Installed | Intel Celeron 4205U |
| Socket | CPU onboard |
| Max CPU frequency | 1.8 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210, Intel i219 |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 3 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 2 |
| RS-232/422/485 | 4 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 2 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | Yes, 1 |
Connectors | |
| Connectors | HDMI, 3xRJ45 Ethernet, 6xUSB, Display Port, 4xDB9 Male, 2xRJ45 (COM) |
System Power Input | |
| Input Voltage DC | 12...24 V |
Software | |
| Operating System Compatibility | Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 190 mm |
| Height | 150 mm |
| Depth | 81 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Vibration | MIL-STD-810G 514.6C-1 (SSD) |
| Shock | Half-sine wave shock 5G. 11ms. 100 shocks per axis. IEC68-2-27 |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810F Test Method 514.5C-1 Vibration |
