Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Wall, DIN-Rail mount, Wall VESA 75 |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron J1900 |
| Max CPU frequency | 2.42 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| RS-232 | 2 |
| USB Total | 4 |
| USB 2.0 | 3 |
| USB v3.x | 1 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 64 GB |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | 1 |
Connectors | |
| Connectors | 2xDB9, DB15 VGA, HDMI, 2xRJ45 Ethernet, 4xUSB, Mic In, DC Input, Display Port |
System Power Input | |
| Input Voltage DC | 19...19 V |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 8, Windows Embedded Standard 8, Linux OS, Fedora |
Dimensions and weight | |
| Width | 204 mm |
| Height | 118.2 mm |
| Depth | 44.2 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE/FCC, FCC Class B |
| Safety | CCC, CB, UL, BSMI |
