DSCT47S-10

Name: DSCT47S-10
Brand: Dataforth
SKU: 02410900
Availability: InStock

Dataforth

Ціна за запитом

Linearized Thermocouple Input Transmitter, Type S, Input +500...+1750 °C, Output 4...20 mA

Специфікація

Specification

Analog Input
Thermocouple	S: +500...+1750°C
Total channels of analog input	1
Analog Output
Channels of analog input	1
Current range	4...20 mA
Construction
Construction Chassis	Plastic Chassis
Mounting Configuration	DIN-Rail mount
Connectors
Connectors	Screw Terminal
Dimensions and weight
Width	22.5 mm
Depth	105 mm
Height	75 mm
Operating Conditions
Operating Temperature	-40...80 °C
Standards and Certifications
Certifications	CE, IEC 61000-6-2
EMI	EN 61000-6-4
EMS	IEEE C37.90.1
