Construction | |
| Construction Chassis | Magnesium Alloy |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
| Type | Fan |
Display | |
| Display Type | LCD TFT |
| Diagonal | 11.6 " |
| Maximum resolution | 1920x1080 Dots |
| Brightness | 360 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Core i5-8250U |
| CPU Support Type | Core i7 |
| Max CPU frequency | 3.4 GHz |
Memory | |
| Default on Board Memory | 8 GB |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Wi-Fi | |
| Wi-Fi Standard | 802.11ac/a/b/g/n |
Interfaces | |
| USB Total | 2 |
| USB v3.x | 2 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| M.2 | 1 |
| MicroSD | 1 |
| MicroSDHC | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| 1st Storage Capacity | 128 GB |
Extension Slots | |
| SIM Card slots | Yes |
Additional Functions | |
| Camera Frontside | 2 MP |
| Rear Camera | 5 MP |
| GPS | GPS |
| RFID Reader | Optional |
| NFC | Yes |
| Watchdog timer type | Software |
Antenna characteristics | |
| Cellular interfaces | 4G |
| Bluetooth | v4.0 |
LED / Controls | |
| LED | Battеry Status, Power LED, WLAN LED |
| Controls | On/Off, Control Buttons |
Connectors | |
| Connectors | 2xUSB, DC Input, SIM Card Slot, MicroSD card slot, Jack 3.5 |
| Docking Station | Yes |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 65 W |
Battery | |
| Battery 1 Technology | Li-pol |
| Battery Capacity | 4130 mA*h |
| RunTime Battery 1 | 0 h |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 298 mm |
| Height | 20 mm |
| Depth | 192 mm |
Operating Conditions | |
| Operating Temperature | -10...55 °C |
Standards and Certifications | |
| MIL-STD-810 | MIL-STD-810G Test Method 500.5 Low Pressure (Altitude), MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
