Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall |
| Protection Level of Chassis | IP67 |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Apollo Lake |
| Processor Installed | Intel Celeron N3350 |
| Socket | FCBGA1296 |
| Max CPU frequency | 2.4 GHz |
Chipset | |
| Chipset | Intel Apollo Lake SoC |
Memory | |
| Form-factor | DDR3 |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 4 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| USB Total | 2 |
| USB 2.0 | 1 |
| USB v3.x | 1 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 64 GB |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
LED / Controls | |
| LED | Power LED |
Connectors | |
| Connectors | 2xRJ45 Ethernet, 1xUSB, USB type C, M12 DC-in |
System Power Input | |
| Input Voltage DC | 9...36 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 36 W |
Software | |
| Operating System Compatibility | Ubuntu, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 100 mm |
| Height | 115 mm |
| Depth | 31 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Humidity | 10-90% |
Standards and Certifications | |
| Certifications | CE, FCC |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
