System Architecture | |
| Form Factor | 3.5" |
CPU | |
| СPU Generation/Family | Bay Trail |
| CPU Support Type | Atom |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Intel Gen7 graphic engine |
| Interfaces | HDMI, VGA |
Ethernet | |
| Controller Type | Intel i210 |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 4 |
Audio | |
| Audio Controller | Realtek ALC888 |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 4xDB9, DB15 VGA, HDMI, 2xRJ45, 4xUSB, Mic In, Line Out, DB15 GPIO |
Dimensions and weight | |
| Width | 102 mm |
| Length | 146 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
