System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fan |
CPU | |
| Processor Installed | Intel Atom x5-E3930 |
| Max CPU frequency | 1.8 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 2xSODIMM |
| Maximum Memory | 16 GB |
Graphic | |
| Graphic Controller | Integrated in Chipset |
| Interfaces | LVDS, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i210-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
Audio | |
| Audio Controller | Realtek ALC886 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| SIM Card slots | 1 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Internal Ports | 4xCOM, 10-pin RS-232, 10-pin RS-232/422/485 |
| Connectors | DB15 VGA, LVDS, HDMI, 2xRJ45 Ethernet, 4xUSB, External SATA |
Dimensions and weight | |
| Width | 102 mm |
| Length | 146 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
