Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall VESA 100 |
| Type | Fanless |
CPU | |
| Processor Installed | Vortex86DX2 |
| Max CPU frequency | 0.93 GHz |
Memory | |
| Form-factor | DDR2 |
| ECC | No |
| Default on Board Memory | 1 GB |
| Maximum Memory | 2 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-485 | 1 |
| USB Total | 3 |
| USB 2.0 | 3 |
Drive interfaces | |
| SD Slots | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Connectors | |
| Connectors | 4xDB9, DB15 VGA, 2xRJ45, 3xUSB, Line Out, DC Input |
System Power Input | |
| Input Voltage DC | 8...15 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Dimensions and weight | |
| Width | 115 mm |
| Height | 35 mm |
| Depth | 115 mm |
Operating Conditions | |
| Operating Temperature | 5...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC, VCCI |
