Construction | |
| Mounting Configuration | Wall VESA 100 |
CPU | |
| Max CPU frequency | 1 GHz |
Memory | |
| Form-factor | DDR3 |
| Default on Board Memory | 2 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| RS-232 | 2 |
| USB Total | 4 |
| USB 2.0 | 4 |
Drive interfaces | |
| mSATA | 1 |
| CFast Slots | 1 |
Connectors | |
| Connectors | DB15 VGA, 2xRJ45 Ethernet, 4xUSB, Line Out |
System Power Input | |
| Input Voltage DC | 8...24 V |
Dimensions and weight | |
| Width | 115 mm |
| Height | 115 mm |
| Depth | 35 mm |
Operating Conditions | |
| Operating Temperature | 5...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC, VCCI |
