Construction |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Built-in, Desktop |
| Protection Level of Chassis | IP40 |
| Type | Fanless |
CPU |
| СPU Generation/Family | Haswell |
| Socket | LGA1150 |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7 |
Chipset |
| Chipset | Intel Q87 |
Memory |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 16 GB |
Ethernet |
| Controller Type | Intel i210-IT, Intel i217LM 10/100/1000 Mbps |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces |
| COM Total | 6 |
| RS-232/422/485 | 6 |
| USB Total | 6 |
| USB v3.x | 6 |
Digital Input-Output |
| Channels of DIO | 32 |
Drive interfaces |
| RAID Levels | 1 |
| mSATA | 1 |
| CFast Slots | 1 |
Storage Cage |
| Number Of Cage External | 2 |
| 2.5" Cage Intenal | 2 |
Extension Slots |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | Yes, 1 |
Connectors |
| Connectors | 6xDB9, DB44, DB15 VGA, 2xHDMI, 4xRJ45, 6xUSB, Display Port, DC input (terminal block) |
System Power Input |
| Input Voltage DC | 9...36 V |
Software |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Linux OS |
Dimensions and weight |
| Width | 280 mm |
| Height | 70 mm |
| Depth | 190 mm |
Operating Conditions |
| Operating Temperature | -40...55 °C |
| Vibration | CFast: 3 Grms. 5...500Hz. X. Y. Z directions |
Standards and Certifications |
| Certifications | CE |
| Safety | EN 60950 |
