Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP40 |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Skylake |
| Socket | LGA1151 |
| CPU Support Type | Core i7, Core i5, Core i3, Celeron |
Chipset | |
| Chipset | Intel H110 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Integrated in Chipset |
Ethernet | |
| Controller Type | Intel i210-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| PCI | 1 |
| SIM Card slots | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xHDMI, 4xRJ45 Ethernet, 6xUSB, 4xSMA, 1xDP, 2xRJ45 (COM), Audio Mic |
System Power Input | |
| Input Voltage DC | 9...32 V |
Software | |
| Operating System Compatibility | Linux OS, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 280 mm |
| Height | 76 mm |
| Depth | 190 mm |
Operating Conditions | |
| Operating Temperature | -40...50 °C |
| Vibration | 3 Grms с SSD 5 ~ 500Hz |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
