Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP40 |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Comet Lake |
| Socket | LGA1200 |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7 |
Chipset | |
| Chipset | Intel H420E |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | Yes |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DisplayPort, HDMI, 2xHDMI |
Ethernet | |
| Controller Type | Intel i210-IT, Intel i219-LM |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB v3.x | 6 |
Drive interfaces | |
| SATA 3 | 2 |
| RAID Levels | 1 |
| mSATA | 2 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage External | 2 |
Extension Slots | |
| Total | 4 |
| PCI Express x4 | 1 |
| M.2 | 1 |
| M.2 Form Factor | 3050 B |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | 2 |
LED / Controls | |
| LED | 1xHDD LED, Power LED |
| Controls | AT/ATX Switch, On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 6xUSB, DC Input, Display Port, 4xDB9, 2xHDMI, 4xRJ45 Ethernet |
System Power Input | |
| Input Voltage DC | 9...48 V |
Software | |
| Operating System Compatibility | Linux OS, Windows IoT Enterprise 10, Windows 10, Windows 11 |
Dimensions and weight | |
| Width | 280 mm |
| Height | 80.5 mm |
| Depth | 210 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
| Humidity | 10-90% |
Standards and Certifications | |
| Certifications | EAC, CE/FCC |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
