Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
CPU | |
| Processor Installed | Intel Core i7-6600U |
| Socket | LGA1151 |
| Max CPU frequency | 3.4 GHz |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 8 GB |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232/422/485 | 4 |
| USB Total | 4 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | DB15 VGA, HDMI, Mic In, Line Out |
System Power Input | |
| Input Voltage DC | 15...36 V |
Dimensions and weight | |
| Width | 57 mm |
| Height | 181.6 mm |
| Depth | 118.4 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
