Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Digital Output | |
| Total channels of digital output | 16 |
| Type | Open emmiter |
| Sink/Source | Source |
| Output voltage | 3.5~30 V |
| Max. load current | 100 mA |
Supported Protocols | |
| Industrial Protocols | EtherCAT slave |
Connectors | |
| Connectors | Screw Terminal |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 33 mm |
| Depth | 90 mm |
| Height | 110 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| EMS | IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5 |
