Specification
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
Digital Input | |
| Total channels of digital input | 8 |
| Type | Wet contact |
| Level of Logic "0" | 0~5 V |
| Level of Logic "1" | 10~30 V |
| Isolation of Digital Input | 3750 V |
| Number of channels | 4 |
| Max frequency | 4 kHz |
Digital Output | |
| Total channels of digital output | 2 |
| Type | Open collector |
| Output voltage | 5~30 V |
| Max. load current | 100 mA |
| Channels | 4 |
Ethernet | |
| Total Ethernet | 2 |
Supported Protocols | |
| Industrial Protocols | EtherCAT slave |
System Power Input | |
| Input Voltage DC | 20...30 V |
Dimensions and weight | |
| Width | 33 mm |
| Depth | 110 mm |
| Height | 181 mm |
Operating Conditions | |
| Operating Temperature | -25...40 °C |
Standards and Certifications | |
| EMS | IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5 |
