Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop, Wall, Wall VESA 100 |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron 2000E |
| Max CPU frequency | 2.2 GHz |
Chipset | |
| Chipset | Intel QM87 |
Memory | |
| Form-factor | DDR3 |
| Socket Type | 1xSODIMM |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes, 802.11b/g/n |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 6 |
| USB 2.0 | 4 |
| USB v3.x | 2 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage Intenal | 2 |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | 2xDB9, DB15 VGA, 2xHDMI, 2xRJ45, 6xUSB, Mic In, Line Out, DC Input |
System Power Input | |
| Input Voltage DC | 9...36 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Dimensions and weight | |
| Width | 265 mm |
| Height | 56.7 mm |
| Depth | 134 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Vibration | MIL-STD-810F 514.5C-2 (with SSD) |
| Shock | Half-sine wave shock 5G. 11ms. 3 shocks per axis |
Standards and Certifications | |
| MIL-STD-810 | MIL-STD-810F Test Method 514.5C-2 Vibration |
