Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, 19" Rackmount |
| Height | 1 U |
| Type | Fanless |
CPU | |
| Processor Installed | ARM Cortex A8 |
| Max CPU frequency | 0.8 GHz |
Memory | |
| Form-factor | DDR3 |
| Default on Board Memory | 1 GB |
| Assembly | Fixed on Board |
Ethernet | |
| Total Ethernet | 4 |
| 10/100 Mbit/s | 4 |
Interfaces | |
| COM Total | 16 |
| RS-232/485 | 16 |
| USB Total | 1 |
| USB 2.0 | 1 |
Installed drive | |
| Storage Form-Factor | MicroSD |
| 1st Storage Capacity | 1 GB |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 4xRJ45 Ethernet |
System Power Input | |
| Input Voltage AC | 100...240 V |
Software | |
| Operating System Compatibility | Linux OS |
Dimensions and weight | |
| Width | 440 mm |
| Height | 44.5 mm |
| Depth | 220 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
| Vibration | IEC 68 2-64 (Random 1 Oct./min. 1hr/axis.) CompactFlash: 2 Grms @ 5 ~ 500 Hz |
| Shock | IEC 68 2-27 CompactFlash®: 30 G half sine. 11 ms |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
