Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 2 U |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i7-4650U |
| Max CPU frequency | 3.3 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 8 GB |
| Maximum Memory | 16 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DVI, VGA |
Ethernet | |
| Total Ethernet | 8 |
| 10/100/1000 Mbit/s | 8 |
Interfaces | |
| COM Total | 10 |
| RS-232 | 2 |
| RS-232/422/485 | 8 |
| USB Total | 6 |
| USB 2.0 | 6 |
Drive interfaces | |
| RAID Levels | 1 |
| CFast Slots | 1 |
Storage Cage | |
| 2.5" Cage Intenal | 2 |
Extension Slots | |
| Total | 2 |
| PCI Express x1 | 1 |
| PCI | 1 |
LED / Controls | |
| LED | 1xHDD LED, Power LED, LAN LED, TX LED, RX LED |
| Controls | 1xOn/Off, 1xReset |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xDB9, DVI, DB15 VGA, 2xDC input (terminal block), 8xRJ45 Ethernet, 8xCOM (terminal block) |
System Power Input | |
| Input Voltage AC | 100...240 V |
| Input Voltage DC | 100...240 V |
Power Supply | |
| Type of Power Supply | Industrial |
| Supported Types of Power Supply | Redundant |
Software | |
| Operating System Compatibility | Windows Server 2008, Windows 7, Windows Embedded Standard 7, Linux OS, Windows Embedded Standart 8.1 |
Dimensions and weight | |
| Width | 440 mm |
| Height | 88 mm |
| Depth | 280 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
| Vibration | IEC 60068-2-64 (Random 1 Oct./min. 1hr/axis.) CFast: 2 Grms 5 ~ 500 Hz. HDD: 1 Grms 5 ~ 500 Hz |
| Shock | IEC 68 2-27 CFast: 50 G half sine. 11 ms HDD: 20 G half sine. 11 ms |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Power Automation | IEEE 1613, IEC 61850-3 |
