Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, 19" Rackmount |
| Height | 2 U |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Xeon E3-1505L v5 |
| Max CPU frequency | 2.8 GHz |
Memory | |
| Form-factor | DDR4 |
| ECC | Yes |
| Default on Board Memory | 16 GB |
Graphic | |
| Interfaces | DVI-D, VGA |
Ethernet | |
| Total Ethernet | 8 |
| 10/100/1000 Mbit/s | 8 |
Interfaces | |
| COM Total | 10 |
| RS-232 | 2 |
| RS-232/422/485 | 8 |
| USB Total | 6 |
Drive interfaces | |
| CFast Slots | 1 |
Extension Slots | |
| PCI Express x1 | 1 |
| PCI | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DVI-D, DB15 VGA, 6xUSB |
System Power Input | |
| Input Voltage AC | 100...240 V |
Power Supply | |
| Type of Power Supply | Industrial |
| Supported Types of Power Supply | Redundant |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 8, Linux OS |
Dimensions and weight | |
| Width | 440 mm |
| Height | 88 mm |
| Depth | 280 mm |
Operating Conditions | |
| Operating Temperature | -25...60 °C |
| Vibration | IEC 68-2-64 (Random 2Grms. 5~500Hz for SSD) |
| Shock | IEC 68 2-27 CFast®: 10 G half sine.11 ms |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Power Automation | IEEE 1613, IEC 61850-3 |
