Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 2 U |
| Type | Fans |
CPU | |
| СPU Generation/Family | Skylake |
| Socket | LGA 3647-P0 |
| CPU Support Type | Xeon |
Chipset | |
| Chipset | Intel C622 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 12xDIMM |
| ECC | Yes |
| Maximum Memory | 768 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Aspeed AST 2500 |
| Interfaces | VGA, 2xDVI |
Ethernet | |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces | |
| USB Total | 3 |
| USB v3.x | 3 |
Drive interfaces | |
| M.2 | 1 |
Storage Cage | |
| 2.5" Cage External | 4 |
Extension Slots | |
| Total | 6 |
| PCI Express x16 | 2 |
| PCI Express x8 | 1 |
| PCI Express x4 | 1 |
| PCI Express x1 | 1 |
| PCI | 1 |
LED / Controls | |
| LED | Power LED, LAN LED |
| Controls | On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB15 VGA, 4xRJ45 Ethernet, 3xUSB, 2xDVI |
System Power Input | |
| Input Voltage AC | 100...240 V |
| Input Voltage DC | 100...240 V |
Power Supply | |
| Type of Power Supply | Industrial, Redundant, Internal |
| Output Power | 800 W |
| Quantity of Power Modules | 2 |
| Input Voltage AC | 100...240 V |
| Input Voltage DC | 100...240 V |
Software | |
| Operating System Compatibility | Windows Server 2016, Windows Server 2019 |
Dimensions and weight | |
| Width | 440 mm |
| Height | 88 mm |
| Depth | 460 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC, CB |
| Power Automation | IEC 61850-3, IEEE 1613 |
