Системи промислової автоматизації
Specification
Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus TCP, Modbus RTU slave, Modbus RTU master, Modbus RTU, Modbus ASCII slave, Modbus ASCII master, Modbus ASCII |
LED / Controls | |
| LED | STATE LED, 10/100M LED, TX LED, RX LED, PWR1, PWR2 |
System Power Input | |
| Redundant power input | Yes |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Dimensions and weight | |
| Width | 37 mm |
| Depth | 95 mm |
| Height | 140 mm |
Standards and Certifications | |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
