Specification
Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
| Type 10/100 Mbit/s | 2xRJ-45 |
Interfaces | |
| COM Total | 4 |
| RS-232/422/485 | 4 |
LED / Controls | |
| LED | Power LED, 10/100M LED, TX LED, RX LED |
System Power Input | |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 48.6 mm |
| Depth | 95 mm |
| Height | 140 mm |
Standards and Certifications | |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
