Ethernet |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
| Type 10/100 Mbit/s | 1xSC, 1xRJ-45 |
Fiber |
| Number of Optical Ports | 1xSC |
| Type of Fibre Optic | multi-mode |
LED / Controls |
| LED | Power Fail, 10/100M LED, PWR1, PWR2 |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 37 mm |
| Depth | 95 mm |
| Height | 140 mm |
Standards and Certifications |
| EMI | EN 55022 Class A, FCC Part 15 Subpart B Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-7, EN 61000-4-8 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 60950-1, CSA C22.2 No. 60950-1 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
