Ethernet |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
| SFP 100/1000 Mbit Ports | 1 |
| Type 10/100/1000 Mbit/s | RJ-45 |
Digital Output |
| Total channels of digital output | 1 |
| Type | Electromagnitic relay |
Supported Protocols |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
Switch Properties |
| Supported functions | Automatic power failure notification, Link Fault Pass-Through (LFP) |
LED / Controls |
| LED | FAULT LED, PWR1, PWR2 |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 30 mm |
| Depth | 95 mm |
| Height | 140 mm |
Standards and Certifications |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 60950-1 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
