Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Elkhart Lake |
| Processor Installed | Celeron N6210 |
| Socket | FCBGA1493 |
| Max CPU frequency | 2.6 GHz |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics |
| Interfaces | 2xHDMI, DisplayPort |
Ethernet | |
| Controller Type | Intel i225V |
| Total Ethernet | 2 |
| 2,5 Gbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 5 |
| USB 2.0 | 1 |
| USB v3.x | 4 |
Drive interfaces | |
| M.2 | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 32 GB |
Extension Slots | |
| Total | 2 |
| M.2 | 2 |
| M.2 Form Factor | 2280 M, 2260 M, 2230 E |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB9, 2xHDMI, 2xRJ45 Ethernet, 3xUSB, DC Input, Display Port, USB type C |
System Power Input | |
| Input Voltage DC | 12...12 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Windows 11 |
Dimensions and weight | |
| Width | 118 mm |
| Height | 108 mm |
| Depth | 48 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Humidity | 10-95% |
| Vibration | 3 Grms/5~500Hz/random operation |
| Shock | Operating 50G (11ms) with eMMC |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
