Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall |
| Type | Fan |
CPU | |
| Processor Installed | AMD Ryzen V1807B |
| Max CPU frequency | 3.8 GHz |
Chipset | |
| Chipset | SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, AMD Radeon Graphics Vega |
| Interfaces | 4xDisplayPort |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| Total | 2 |
| M.2 | 1 |
| M.2 Form Factor | 2280 M, 2242 M |
| Mini-PCIe/Mini Card | 1 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Connectors | |
| Connectors | 2xDB9, 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out, DC input (terminal block), 4xDisplayPort |
System Power Input | |
| Input Voltage DC | 9...36 V |
| Power Consumption | 65 W |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Linux kernel 3.x |
Dimensions and weight | |
| Width | 240 mm |
| Height | 204 mm |
| Depth | 41 mm |
Operating Conditions | |
| Operating Temperature | -10...50 °C |
| Humidity | 10-95% |
| Vibration | 5~500Hz 3 Grms X.Y. Z axis w/storage |
| Shock | 10G peak acceleration (11 m sec. duration). operation; 30G peak acceleration (11 m sec. duration). nonoperation |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
