System Architecture | |
| Form Factor | COM Express CPU Module |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i7-4700EQ |
| Max CPU frequency | 3.4 GHz |
Chipset | |
| Chipset | Intel QM87 |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel HD Graphics 4600 |
| Interfaces | DVI, LVDS, DDI |
Ethernet | |
| Controller Type | Intel i217LM 10/100/1000 Mbps |
Interfaces | |
| USB Total | 12 |
| USB 2.0 | 8 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Intel HD Audio |
Extension Slots | |
| PCI Express x16 | 1 |
| PCI Express x1 | 8 |
Additional Functions | |
| Watchdog timer type | Software |
Software | |
| Operating System Compatibility | Windows 7, Windows 8, Linux OS |
Dimensions and weight | |
| Width | 125 mm |
| Length | 95 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
