System Architecture | |
| Form Factor | COM Express Mini |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom E3845 |
| Max CPU frequency | 1.91 GHz |
Chipset | |
| Chipset | Intel Bay Trail-I SoC |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 2 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Intel Gen7 graphic engine |
| Interfaces | LVDS, DDI |
Ethernet | |
| Controller Type | Intel i210-IT |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| USB Total | 9 |
| USB 2.0 | 8 |
| USB v3.x | 1 |
Extension Slots | |
| Total | 3 |
| PCI Express x1 | 3 |
Connectors | |
| Internal Ports | 220-pin COM Express |
Software | |
| Operating System Compatibility | Windows 7, Windows 8, Ubuntu |
Dimensions and weight | |
| Width | 55 mm |
| Length | 84 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
