Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron J1900 |
Memory | |
| Socket Type | 1xSODIMM 204pin |
| ECC | No |
| Default on Board Memory | 2 GB |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Integrated in Chipset |
Ethernet | |
| Total Ethernet | 5 |
| 10/100/1000 Mbit/s | 5 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 5 |
| USB 2.0 | 4 |
Audio | |
| Audio Controller | Realtek ALC892 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | DB15 VGA, Mic In, Line In, Line Out, 2xPS/2 Keyboard/Mouse |
Software | |
| Operating System Compatibility | Windows 7, Windows 8, Linux OS |
Dimensions and weight | |
| Width | 240 mm |
| Height | 170 mm |
| Depth | 60 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
