Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i5-2510E |
| Max CPU frequency | 3.1 GHz |
Chipset | |
| Chipset | Intel QM67 |
Memory | |
| Form-factor | DDR3 |
| Socket Type | 1xSODIMM |
| ECC | No |
| Default on Board Memory | 2 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DVI-I |
Ethernet | |
| Controller Type | Integrated with Chipset |
| Total Ethernet | 6 |
| 10/100/1000 Mbit/s | 6 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 4 |
| USB v3.x | 2 |
Digital Input-Output | |
| Channels of DIO | 16 |
Audio | |
| Audio Controller | AC97 |
Drive interfaces | |
| RAID Levels | 1 |
| CFast Slots | 1 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage Intenal | 2 |
Installed drive | |
| Drive Type | HDD |
| 1st Storage Capacity | 320 GB |
Connectors | |
| Connectors | DB37 Female, DVI-I, PS/2 Keyboard/Mouse, 6xRJ45 Ethernet, 6xUSB, Mic In, Line Out, DC input (terminal block), DB62 Female |
System Power Input | |
| Input Voltage DC | 10...30 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows XP Embedded, Windows 7, Windows Embedded Standard 7, Windows 8 |
Dimensions and weight | |
| Width | 230 mm |
| Height | 82 mm |
| Depth | 206 mm |
Operating Conditions | |
| Operating Temperature | 0...55 °C |
| Vibration | 5 Grms. 5-500 Hz |
Standards and Certifications | |
| Certifications | CE/FCC |
