Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
CPU | |
| СPU Generation/Family | Coffee Lake Refresh |
| Processor Installed | Intel Core i7-9700E |
| Max CPU frequency | 4.4 GHz |
Chipset | |
| Chipset | Intel C246 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | NVIDIA Quadro P2200 GDDR5 5GB |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219 |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 3 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 7 |
| USB 2.0 | 4 |
| USB v3.x | 3 |
Drive interfaces | |
| CFast Slots | 1 |
Storage Cage | |
| Number Of Cage External | 4 |
| 2.5" Cage Intenal | 4 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 512 GB |
Extension Slots | |
| Total | 6 |
| PCI Express x16 | 1 |
| PCI Express x4 | 2 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
| PCI | 1 |
Connectors | |
| Connectors | 4xDB9, 3xRJ45 Ethernet, 7xUSB, Mic In, Line Out, DC input (terminal block) |
System Power Input | |
| Input Voltage DC | 12...24 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 280 W |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Windows 10, Ubuntu 18.04 LTS |
Dimensions and weight | |
| Width | 206 mm |
| Height | 240 mm |
| Depth | 210 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Vibration | Operating: 5 Grms. 5-500 Hz. 3 axes (w/2.5" SSD/CFast) Operating: 0.5 Grms. 5-500 Hz. 3 axes (w/ HDD) |
| Shock | Operating: 50 Grms. half sine 11ms duration (w/ 2.5" SSD/CFast) |
Standards and Certifications | |
| Certifications | CE, FCC Class A, EN61000-6-4, CB |
